BR21882240 “Creation of quasi-high-entropy alloy with the use of Kazakhstani raw materials and technology of production of precision parts on its basis” s.w. Issagulov A.Z.
Relevance
Most of the precision parts of medium and heavy engineering (fittings of gas and oil pipelines, replacement parts of pumps, metallurgical equipment, mining combines, etc.) are currently supplied to Kazakhstan from abroad, which puts the country in economic dependence. Meanwhile, the level of development of metallurgical and foundry production in the Republic of Kazakhstan allows producing its own precision parts from appropriate materials. For example, LWM method (investment casting) and LGM method (casting on gasifiable models) are sufficiently developed, which allow to produce shaped parts of high geometric accuracy and surface cleanliness. It is obvious that the development of own technologies for the production of precision parts is an urgent task of strategic importance for the Republic of Kazakhstan.
Purpose of the program
Development of the composition of quasi-high-entropy alloy (QHEA) using Kazakhstani raw materials and technology of production of precision parts on its basis for medium and heavy engineering.
Expected and achieved results
On the basis of the conducted monitoring the object of research was determined – elements of shut-off and control valves – flanges, sealing rings, disks, which are currently made of high-alloy steels. Structural strength of products and special properties (heat resistance, heat resistance, etc.), as well as structure parameters and phase composition are defined as the subject of research. The FeCrNiCoMn system was determined and justified as the basic system for further studies. The choice of the system is conditioned by good properties demonstrated by alloys of this system. on the basis of the specified system with partial use of ferroalloys as charge components. The obtained results showed the principal possibility of development of this research direction. The raw material base for development and production of KEER with components of Kazakhstani content was determined. Based on the results, an article was submitted to CIS Iron and Steel Review (Moscow, Russia). A program website was created to highlight the scientific results of the Program implementation, transparency of the research team’s activities and to attract potential consumers of the developed technology.
Figure 1 shows the structure of the experimental alloy and the results of MRSA at 4 points. As can be seen from the data in Table 6 and the given characteristic spectrum, Fe, Cr, Mn, Co and Ni are present in the structure, and their concentration practically coincides with the concentration of elements obtained on Poly Spec-F.
The structure of the experimental alloy is represented by a solid solution, presumably of the substitution type with FCC-lattice. The matrix also contains minor inclusions, presumably of silicate nature.
б
Figure 1- Characteristic spectrum of the experimental alloy (a,b,c)
In order to determine the possible risks associated with the presence of inclusions, a quantitative analysis of the main characteristics of the inclusions was performed. Quantitative inclusion characteristics were obtained using Thixomet Pro software (Figure 2)
Figure 2 – Quantitative characteristics of the inclusions obtained with the SW software
Thixomet Pro
Research team
1 Isagulov Aristotel Zeynullinovich – scientific supervisor, D.Sc. in engineering, Professor, Executive Director;
ORCID 0000-0003-2174-9072
Researcher ID: C-7415-2016
Scopus Author ID: 57219418150
2 Ibatov Marat Kenesovich – D.Sc. in engineering, Professor of the Department of “Transport equipment and logistic systems”;
ORCID 0000-0001-5062-7790
Researcher ID N-9320-2017
Scopus Author ID 57189211438
3 Kulikov Vitaly Yuryevich – responsible executor, Cand. Sc. Engineering, Professor, Head of the Department of Nanotechnology and Metallurgy;
ORCID 0000-0001-6191-8569
Researcher ID: N-5596-2017
Scopus Author ID: 56168395900
4 Kvon Svetlana Sergeyevna – Cand. Sc. Engineering, Professor of the Department of Nanotechnology and Metallurgy;
ORCID 0000-0002-5439-4426
ResearcherID: N-5602-2017
Scopus Author ID: 57061892400
5 Koshebaeva Gauhar Kapenovna – D.Sc. in engineering, Professor of the Department of “Economics and Management of Enterprises”;
ORCID 0000-0002-0393-9844
Scopus Author ID: 56512359700
6 Arinova Sania Kaskataevna – PhD, lecturer at the Department of Nanotechnologies and Metallurgy;
Scopus Author ID 57192206332
7 Dostaeva Ardak Muhamedievna – PhD, Acting Associate Professor of Nanotechnology and Metallurgy Department;
ORCID 0000-0002-1982-2368
Researcher ID AAB-9478-2020
Scopus Author ID: 57160297400
8 Shcherbakova Elena Petrovna – PhD, Acting Associate Professor of the Nanotechnology and Metallurgy Department;
ORCID 0000-0001-6678-6673
Researcher ID N-5639-2017
Scopus Author ID: 57211287717
9 Issagulova Diana Aristotelevna – PhD, Acting Associate Professor of Nanotechnology and Metallurgy Department;
Scopus ID 55778253200
10 Aubakirov Dastan Rakhmetollayevich – PhD, Senior Lecturer of Nanotechnology and Metallurgy Department;
ORCID 0000-0003-4193-5956
Scopus Author ID: 57194209750
11 Sultangaziev Ruslan Bauyrzhanovich – PhD, Acting Associate Professor of Nanotechnology and Metallurgy Department;
ORCID 0000-0002-3928-486X
Scopus Author ID: 57160291200
12 Dospaev Murat Mantenovich – D.Sc. in engineering, Senior Scientific Staff member of RSE “National Center on Complex Processing of Mineral Raw Material of the RK” “Zh. Abishev CMI”;
Scopus Author ID: 57204315025
13 Figurinene Irina Vladislavovna – Candidate of Chemical Sciences, Associate Professor of “Karaganda Medical University” NJSC;
Scopus Author ID: 56951245900
14 Kazhikenova Saule Sharapatovna – Doctor of Technical Sciences, Professor, Head of the Department of Higher Mathematics;
ORCID 0000-0002-6937-1577
ResearcherID: P-5627-2017
Scopus Author ID: 36106908300
15 Shaltakov Sagyndyk Nagashibaevich – PhD, Acting Associate Professor of the Department of Physics;
16 Narembekova Aitbala, Ph.D., Associate Professor of the Department of Nanotechnology and Metallurgy;
ORCID 0000-0002-9066-6564
Scopus Author ID: 56505474200
17 Tulegenova Sholpan Nygmetovna – M. Sc.in engineering, Senior Lecturer of the Department of Nanotechnology and Metallurgy;
18 Omarova Aidana Yerzhanovna – M. Sc.in engineering, doctoral student of the Department of Nanotechnology and Metallurgy;
ORCID 0000-0002-6942-2020
Scopus ID 56901129500
19 Alina Araylym Altynbekovna – M.Sc. in engineering, lecturer of “Nanotechnology and Metallurgy” department;
ORCID 0000-0003-3577-4914
Scopus Author ID: 57218196165
20 Aitbaev Nurlan Berikuly – M.Sc. in engineering, Senior Lecturer of the Department of Nanotechnology and Metallurgy;
Scopus Author ID: 57209175127
21 Kovalyova Tatiana Viktorovna – M.Sc. in engineering, S.Sc. KazMRDI;
ORCID 0000-0002-1186-1805
Researcher ID : A-2567-2017
22 Adamova Gulden Hasenovna – M.Sc. in engineering, doctoral student of the Department of Nanotechnology and Metallurgy;
ORCID 0000-0001-6933-6571
Scopus Author ID: 57265976400
23 Syzdykova Raushan Amanbekovna – Head of the laboratory of the Department of Nanotechnology and Metallurgy;
24 Shokubasova Saltanat Romazanovna – Head of Settlement Department;
25 Abdrakhmanov Mirhat Suendikovich – M.Sc. in engineering, engineer of “Nanotechnologies and Metallurgy” department.
Information for potential users
The target markets of the proposed products are enterprises of metallurgical and foundry specialization, but indirectly, as potential consumers of finished machine-building products, such sectors as mining, metallurgical, enrichment, oil and others.
The developed technology can be implemented at any enterprise of these sectors of economy irrespective of geographical affiliation, form of ownership of the enterprise and volume of output.
